Class AB Amplifier

Rated Power:

100 W x 4 @ 4 Ohm Stereo

150 W x 4 @ 2 Ohm Stereo

300 W x 2 @4 Ohm Bridged

Input Sensitivity:800mV-8V

Frequency Response:10HZ-40kHZ

Highpass/ Lowpass (-3dB, 12dB/0ct):50HZ-250HZ

Signal to Noise Ratio:>100 dB(Aweighted)

Total Harmonic Distortion:<0.03%

Fuse Rating:2x40A

Dimensions (LxWxH):340 x 180 x 52 mm

Net Weight:3.4KG

Technical Specifications

RMS Power：1200W/1Ω

RMS Power：850W/2Ω

RMS Power：600W/4Ω(14.4V/10%）

Frequency Response：20Hz-250Hz

Signal-to-Noise Ratio：≤ 90dB

Total Harmonic Distortion：≤0.2%

4 Channel Class AB Amplifier Clipping and Distortion Auto-Detection

Technical Specifications

RMS Power：

4 x 100 Watts @4 Ohm Stereo

4 x 150 Watts @2 Ohm Stereo

2 x 300 Watts @4 Ohm Bridged

Input Sensitivity：800mV - 8V

Frequency Response：10Hz - 40kHz

Signal to Noise Ratio：＞100dB

Total Harmonic Distortion：＜0.03%

Dimensions ( L×W×H ) ：340mm x 180mm x 52mm

Mono Class D Amplifier

Technical Specifications

RMS Power：

1 x 320 Watts @4 Ohm Stereo

1 x 600 Watts @2 Ohm Stereo

1 x 1200 Watts @1 Ohm Bridged

Input Sensitivity：0.25V - 5V

Frequency Response：20Hz - 400Hz

Signal to Noise Ratio：90dB

Total Harmonic Distortion：＜0.02%

Dimensions ( L×W×H ) ：155mm x 55mm x 250mm

Mono Class D Amplifier

Technical Specifications

RMS Power：

1 x 170 Watts @4 Ohm Stereo

1 x 310 Watts @2 Ohm Stereo

1 x 500 Watts @1 Ohm Bridged

Input Sensitivity：0.25V - 5V

Frequency Response：20Hz - 400Hz

Signal to Noise Ratio：90dB

Total Harmonic Distortion：＜0.02%

Dimensions ( L×W×H ) ：155mm x 55mm x 165mm

4 Channel Class AB Amplifier Clipping and Distortion Auto-Detection

Technical Specifications

RMS Power：

4 x 150 Watts @4 Ohm Stereo

4 x 250 Watts @2 Ohm Stereo

2 x 500 Watts @4 Ohm Bridged

Input Sensitivity：800mV - 8V

Frequency Response：10Hz - 40kHz

Signal to Noise Ratio：＞105dB

Total Harmonic Distortion：＜0.03%

Dimensions ( L×W×H ) ：450mm x 200mm x 58mm

4 Channel Class D Mini Amplifier

Technical Specifications

RMS Power：

4 x 75 Watts @4 Ohm Stereo

4 x 95 Watts @2 Ohm Stereo

2 x 180 Watts @4 Ohm Bridged

Input Sensitivity：0.4V - 13V

Frequency Response：5Hz - 25kHz

Signal to Noise Ratio：＞90dB

Total Harmonic Distortion：＜0.2%

Dimensions ( L×W×H ) ：150mm x 75mm x 43mm

2 Channel Class D Mini Amplifier

Technical Specifications

RMS Power：

2 x 90 Watts @4 Ohm Stereo

2 x 120 Watts @2 Ohm Stereo

1 x 240 Watts @4 Ohm Bridged

Input Sensitivity：0.4V - 13V

Frequency Response：5Hz - 25kHz

Signal to Noise Ratio：＞90dB

Total Harmonic Distortion：＜0.2%

Dimensions ( L×W×H ) ：86mm x 64mm x 43mm

4 Channel Class AB Amplifier

Technical Specifications

RMS Power：

4 x 110 Watts @4 Ohm Stereo

4 x 180 Watts @2 Ohm Stereo

2x 280 Watts @4 Ohm Bridged

Input Sensitivity：200mV - 4V

Frequency Response：10Hz - 40kHz

Signal to Noise Ratio：＞100dB

Total Harmonic Distortion：＜0.02%

Dimensions ( L×W×H ) ：355mm x 200mm x 55mm

2 Channel Class AB Amplifier

Technical Specifications

RMS Power：

2 x 185 Watts @4 Ohm Stereo

2 x 300 Watts @2 Ohm Stereo

1 x 400 Watts @4 Ohm Bridged

Input Sensitivity：200mV - 4V

Frequency Response：10Hz - 40kHz

Signal to Noise Ratio：＞100dB

Total Harmonic Distortion：＜0.02%

Dimensions ( L×W×H ) ：355mm x 200mm x 55mm
