Technical Specifications

Output Power:

Rated: 8CH × 35W + 4CH × 80W

Peak: 8CH × 65W + 4CH × 150W

Frequency Response：20Hz-20kHz

Signal to Noise Ratio：≥98dB

THD：≤0.03%

Dimensions(LxWxH)：242x 240 x 52mm

Class D Power Amplifier Sound Effect Processor

Technical Specifications

Inputs: 4-channel high level, AUX, optical fiber, Bluetooth, USB, OTG

Outputs: 8-channel low level RCA, 4-channel high level

Power: 70W

Frequency Response: 20Hz-20kHz

Signal-to-Noise Ratio: ≥98dB

DHD: ≤0.03%

280W High-Power Amplifier DSP

Technical Parameters

Input Signal: 4-channel High Level, 2-channel Low Level, Built-in Bluetooth

Output Signal: 8-channel Low Level, 4×70W Power

Input Sensitivity: 5.5Vpp (Low Pass), 28Vpp (High Pass)

Impedance: 51 Ohm

Frequency Response: 20Hz–20kHz

Signal-to-Noise Ratio: ≥90dB

Total Harmonic Distortion: ≤0.05%

Dimensions (L×W×H): 178mm×150mm×40mm

8ch sound processor amplifier

Supports DRC Mini/DRC PRO

Technical Specifications

Peak Power：6ch x 150W

Frequency Response：20Hz-20kHz

Dynamic Range：≥102dB

Signal to Noise Ratio：≥98dB

THD：≤0.03%

Dimensions(LxWxH)：318 x 50 x 50mm

6ch sound processor amplifier

Supports DRC Mini/DRC PRO

Technical Specifications

Peak Power：4ch x 50W

Frequency Response：20Hz-20kHz

Dynamic Range：≥102dB

Signal to Noise Ratio：≥98dB

THD：≤0.03%

Dimensions(LxWxH)：177x126 x 42mm

6 Channel DSP with 4 Channel Class AB Amplifier

Technical Specifications

Input Signal：4-channel high level, built-in bluetooth

Output Signal：6-channel low level, 4x50 Watts

Input Sensitivity：5.5Vpp (low level), 28Vpp (high level)

Impedance：51 Ohm

Frequency Response：20Hz - 20kHz

Signal to Noise Ratio：≥90dB

Total Harmonic Distortion：≤0.05%

Dimensions ( L×W×H )：178mm x 119mm x 34mm
