Rainbow Sound Series Vibration Damping Plate not only has excellent vibration damping effect, but also is a flexible waterproof material, representing ultra-thin technological vibration damping products.

Sound Absorption Performance ★★★★★★☆☆☆☆

Sound Insulation Performance ★★★★★★☆☆☆☆

Vibration Damping Performance ★★★★★★★★☆☆

Heat Insulation Performance ★★★★★☆☆☆☆☆

Installation Notes

A. Ensure the installation surface is free of dust, impurities and completely dry;

B. First use a professional solvent to remove grease, and wait for the surface to dry;

C. Remove part of the adhesive film before installation, place the removed part on the edge of the installation area, heat it with a heat gun and press tightly;

D. For the remaining part, continue to gradually remove the anti-adhesive film, place it on the installation surface, heat it, and use a roller to compact it until...

E. Be careful to avoid air bubbles between the material and the installation surface during installation.

Installation Area

Trunk, wheel hub, chassis, engine hood, roof, door, firewall, etc.

Rainbow Professional Series Vibration Damping Plate is the result of research on lightweight sound insulation. It includes double-layer aluminum foil which is extremely hard, and a balm adhesive layer that has an excellent effect on suppressing metal vibration, with superior anti-corrosion and sealing performance.

Sound Absorption Performance ★★★★★★☆☆☆☆

Sound Insulation Performance ★★★★★★★☆☆☆

Vibration Damping Performance ★★★★★★★★★☆

Heat Insulation Performance ★★★★★★☆☆☆☆

Installation Notes

A. Ensure the installation surface is free of dust, impurities and completely dry;

B. First, use a professional solvent to remove grease and wait for the surface to dry;

C. Remove part of the adhesive film before installation, place the removed part on the edge of the installation area, heat it with a heat gun and press it tightly;

D. For the remaining part, continue to gradually remove the anti-adhesive film, place it on the installation surface, heat it, and use a roller to compact it until completion;

E. Be careful to avoid air bubbles between the material and the installation surface during installation.

Installation Area

Trunk, wheel hub, chassis, engine hood, roof, door, firewall, etc.

Rainbow Super Platinum Series Vibration Damping Plate consists of embossed aluminum foil, an elastic organic gel layer and a viscous polymer layer. With high density, strong hardness and great thickness, it can maximize the suppression of automobile sheet metal vibration, control low-frequency noise, and effectively prevent direct contact of water and oxygen with iron plates to avoid rust.

Sound Absorption Performance ★★★★★★★☆☆☆

Sound Insulation Performance ★★★★★★★☆☆☆

Vibration Damping Performance ★★★★★★★★★★

Heat Insulation Performance ★★★★★★★☆☆☆

Installation Notes

A. Clean the installation surface to ensure there is no water, oil stains or other impurities;

B. Remove part of the anti-adhesive film of the product and place the removed part on the installation surface;

C. Then use a heat gun to heat and squeeze the product to make it closely fit the installation surface;

D. Continue the step-by-step construction for the remaining vibration damping plates, heating and pressing to fit until all are completed.

Installation Area

Doors, roof, firewall, wheel hubs, trunk, engine hood, etc.

Rainbow Professional Series Sound Insulation Cotton consists of a non-dent surface layer, an installation layer and a partially closed-cell structure. It has a strong function of blocking noise, excellent heat insulation and thermal preservation effects, and good durability.

Sound Absorption Performance ★★★★★★★★★☆

Sound Insulation Performance ★★★★★★★★★★

Vibration Damping Performance ★★★★★★★★★★

Heat Insulation Performance ★★★★★★★☆☆☆

Installation Notes

A. First, clean the installation surface with a neutral detergent (do not use organic solvents or alkaline liquids) to prevent dust and oil from affecting the product's effect;

B. Then cut the material into the required shape, peel off part of the backing paper, and gradually install the material firmly on the surface;

C. After the material is completely installed on the surface, if necessary, you can carefully roll a roller to compact the surface (do not hit the material hard with a roller knife).

Installation Area

Doors, roof, firewall, wheel hubs, trunk, engine hood, etc.

Rainbow Super Platinum Series Memory Foam is mainly composed of open-cell elastic polyurethane foam. This material has a "memory function". After the unique spatial arrangement developed by R&D engineers, the sound absorption efficiency of the product is greatly improved. It can be applied to sound insulation, vibration damping and heat insulation of various vehicles, with a working temperature range of -40°C to 150°C, and is suitable for plastic parts inside the car.

Sound Absorption Performance ★★★★★★★★★★

Sound Insulation Performance ★★★★★★★☆☆☆

Vibration Damping Performance ★★☆☆☆☆☆☆☆☆

Heat Insulation Performance ★★★★★★☆☆☆☆

Installation Notes

A. First, clean the installation surface with a neutral detergent (do not use organic solvents or alkaline liquids) to prevent dust and oil from affecting the product's effect;

B. Then cut the material into the required shape, peel off part of the backing paper, and gradually install the material firmly on the surface;

C. After the material is completely installed on the surface, if necessary, you can carefully roll a roller to compact the surface (do not hit the material hard with a roller knife).

Installation Area

Door panels, roof, plastic parts in the passenger compartment.

Rainbow Super Platinum Series NB3 is composed of plasticizer, mineral filler, non-woven fabric, butyl rubber and release paper, etc. It has a strong function of reflecting noise. When used with vibration damping plates and sound insulation cotton, it forms a golden partner combination for sound insulation.

Sound Absorption Performance ★★★★★★★☆☆☆

Sound Insulation Performance ★★★★★★★★★☆

Vibration Damping Performance ★★★★★★★★★☆

Heat Insulation Performance ★★★★★★★★★☆

Installation Notes

A. Remove the anti-adhesive film before installation, press carefully and smoothly from the center to the edge on the surface, and wait for the surface to dry;

B. Before installation, the surface must be cleaned of dust, oil stains, etc., and the anti-adhesive paper must be torn off. Apply the product tightly to the surface from the center to the edge, while avoiding air bubbles;

C. If it is necessary to clean the dirt on the installed product, please use water and a neutral detergent that does not contain organic solvents or alkalis.

Installation Area

Chassis, trunk.
